Protocol Based Transceivers

32001353

The 32001353 is a transceiver operating in the 868MHz SRD Band optimized for very long range, low consumption applications, suitable for Low Power Wide Area Network (LPWA networks). Based on Lora™ RF Technology and LoRaWAN™ protocol it provides ultra-long range spread spectrum communication and high interference immunity.

Request information

Highlights

  • Frequency: 868 MHz
  • Dimensions: 26 x 15,5 x 3,16 mm
  • Countries: Europe
  • Protocols: LoRaWAN
  • Certifications: CE, LoRa Alliance
  • Temperature: -40/+85°C

Overview

The 32001353 is a transceiver operating in the 868MHz SRD Band optimized for very long range, low consumption applications, suitable for Low Power Wide Area Network (LPWA networks).

Based on Lora™ RF Technology and LoRaWAN™ protocol it provides ultra-long range spread spectrum communication and high interference immunity.

The transceiver is dedicated for battery operated devices operating in the regional, national or global network. It allows a low-cost secure two-way communication in the Internet of Things. The embedded stack is compliant with LoRaWAN Class A and C specification by Lora Alliance. The module can be configured via UART interface.

The module meets all the requirements in the industrial temperature range -40/+85°C.

The transceiver is RED 2014/53/EU certified and compliant to REACH and RoHS regulations.
