MiP Series

32001605BE8SW

The 32001605BE8SW is a Wireless M-Bus transceiver operating in the 868 MHz SRD Band. Thanks to its small LGA form factor (11.3 mm x 8.9 mm) and its low power consumption, this module allows the implementation of highly integrated low power (battery operated) solutions for water, gas, heat or electricity metering applications, both on meter or concentrator devices. The module supports various operating modes (S, T, R, C) to meet the requirements of one-way or two-way data communication, in stationary and mobile systems. I2C and UARTs allow integration flexibility and easy development of customer products.

Request information

Highlights

  • Frequency: 868 MHz
  • Modulation: FSK
  • Dimensions: 11.3 x 9.8 x 2.5 mm
  • Countries: Europe
  • Protocols: wM-BUS
  • Certifications: CE

Overview


Thanks to its small LGA form factor (11.3 x 8.9 mm) and its low current consumption, this module allows the implementation of highly integrated low power (battery operated) solutions for Internet of Things (IoT) applications especially for smart metering systems like Gas, Water and Energy consumption and management.


Main highlights:

✓ Extremely compact dimensions (1 cm²)

✓ LGA pattern


RF performances:

✓ Up to -115 dBm Sensitivity

✓ +14 dBm Output Power


Low power characteristics:
✓ Sleep (Deep Stop) current consumption 1.5 μA

✓ Shutdown current consumption 14 nA


Protocol and interfaces:

✓ wM-BUS OMS 3
✓ Smart serial interface selector (UART, LPUART, I2C)
